Crux Daemon · 11. Security model

11. Security model

This chapter states what is enforced, what is advisory, and what is not yet wired. Assume nothing that is not listed as enforced.

The daemon-wide threat model lives in docs/THREAT_MODEL.md; this chapter covers the extension surface specifically.

11.1 Trust boundaries

Boundary	Crossed by	Control
Publisher → operator	A manifest	Ed25519 signature over the policy surface; operator keyring is authoritative
Curator → operator	An index	Ed25519 signature; manifest_sha256 pins the whole manifest file
Operator → extension	A grant	Tool allowlist, fact-prefix scopes, rate cap
Extension → fact store	Writes	Grant prefix filter, then the global privacy gate
Daemon → extension endpoint	Outbound HTTP	HTTPS requirement, allowed_hosts, timeout, size caps
WASM module → host	Host ABI calls	Grant scoping, fuel, memory, epoch deadline

11.2 What is enforced

Cryptographically

• Manifest signatures: Ed25519 only, verified against the operator keyring, not against any key the manifest supplies (lib.rs:1411).
• Registry index signatures, with verify_strict (lib.rs:792).
• manifest_sha256 at registry install, compared before the manifest is parsed (http/extensions.rs:310).
• pack_sha256 at Studio library install, likewise compared before the pack is parsed (studio_library.rs:329), with the pack itself required to be signed (studio_library.rs:364).
• WASM wasm_module_sha256, at download and again at every dispatch (wasm_dispatcher.rs:124).
• hashes.manifest, whenever declared (lib.rs:612).

By authorisation

• All 13 extension routes require scopes; every mutation additionally requires facts:write (chapter 9).
• Grant existence, tool allowlist, and fact-prefix scopes, checked in the handler and again in the dispatcher (chapter 5).
• Privacy-gated prefixes are unreachable: rejected at grant issue (extension_grants.rs:92) and again by fact_privacy::enforce_global at every write.
• The MCP catalogue is filtered per calling passport, then again by the RCX capability token (chapter 10).

By resource limit

• Outbound: timeout, request cap, response cap, rate limit — each with a daemon default the manifest can only tighten (chapter 5).
• WASM: fuel, linear memory, wall clock via epoch interruption (chapter 6).
• Downloads: 1 MiB index, 2 MiB manifest, 16 MiB WASM module.
• Vault watcher: 4 MiB per file, 500 files per cycle, 256 KiB cursor.

By path discipline

• safe_path_component on every pack path element (lib.rs:1363).
• WASM module paths rejected if absolute or containing .., at validation and again at resolution (wasm_dispatcher.rs:63).
• Vault watcher refuses symlinks and re-checks canonical containment (vault_watcher.rs:306).

By fail-closed defaults

• Unsigned manifests are rejected unless a named dev flag is on.
• external_helper is rejected unless a named operator flag is on.
• Plain HTTP endpoints are rejected unless a named dev flag is on.
• A malformed allowed_hosts entry never matches (extension_outbound.rs:357).
• A registry index that fails verification is never cached (corecruxctl/src/extensions.rs:120).
• An empty allowed_prefixes_write accepts no writes.

11.3 What is advisory

Do not build a security control on any of these.

Thing	Why it is advisory
risk_level	A derived label for operator display, not an enforcement input (lib.rs:1457)
trust_tier	Operator-assigned metadata. It gates nothing at dispatch
safety.sandbox	A declarative label. The real sandbox is selected by entry.kind
network.requires_user_token	Declared, never read by daemon code
data_access.*	Feeds risk_level only; no runtime check consumes it
tools[].input_schema	Never validated against (lib.rs:160)
Rate limiting	Best-effort — the limiter tolerates mutex poisoning by design (extension_outbound.rs:198)
Audit completeness	Best-effort. Append failures are warn-logged, and the invoke family is capped at 60 events per extension per minute
Console operator posture	A UI gate. The daemon's scope checks are the real control (tests/route_spec_drift.rs:46)
required_tier on a Studio library row	Explicitly not enforced by the daemon. The catalogue server is the gate; the daemon echoes the value and stamps tier_enforcement: "advisory" (studio_library.rs:41)
kind on a Studio library row	A console badge. The pack payload decides what is written, not the declared kind (studio_index.rs:60)

11.4 What is not wired yet

Stated plainly so you do not design around it:

Surface	Status
tools[].auth_shared_secret_id	The transport sends a bearer header, but the invoke handler passes None. No Authorization reaches your endpoint today (http/extensions.rs:784)
crux::get_secret_decrypted	Stub, always -6 NOT_IMPLEMENTED (wasm_host.rs:858)
crux::emit_receipt	Stub, always -6 (wasm_host.rs:868)
WASM response fact_writes[]	Parsed then discarded; use crux::store_fact (wasm_dispatcher.rs:156)
Six of nine entry kinds	Declared vocabulary with no daemon runtime (chapter 2)
Vault-watcher deletions	Recorded in the status detail; no retraction from sealed segments (vault_watcher.rs:77)
Generic encrypted-secrets HTTP surface	Does not exist. Envelopes live inside per-connector files (chapter 7)

11.5 Known-limits an operator should hold in mind

The signature does not cover the endpoint. For an external_tool manifest installed by pasting JSON into /v1/extensions/register, a valid signature says nothing about external_tool_endpoint or tools[]. Only the registry path's manifest_sha256 binds the whole document. Prefer registry installs for anything you did not author.

allowed_hosts is the endpoint allowlist, not an egress firewall. It constrains the endpoint the daemon will POST to. It does not constrain what your service does once called — it can call anything. If egress matters, enforce it at the network layer.

Empty allowed_hosts means unrestricted host. The pin is then the endpoint URL alone (extension_outbound.rs:349). For a signed manifest that is still meaningful; for a dev-bypass unsigned install it is not.

Prefix grants are string prefixes. personal::q permits personal::quotesomething. Always end a granted prefix at a namespace boundary.

Uninstall does not revoke grants. Grant facts survive an uninstall. Reinstall under the same id and old grants apply to the new manifest. Revoke first if the replacement is not equivalent.

Removing a trusted key does not uninstall anything. The trust tier was frozen on the install record at install time (extension_registry.rs:150). Key removal blocks future installs and index verifications.

Everything writes to tenant default. No extension path lets an extension choose a tenant.

Dev bypasses are process-wide. CORECRUXD_EXTENSIONS_ALLOW_UNSIGNED is not per-extension, and CORECRUXD_STUDIO_ALLOW_UNSIGNED is not per-template. With either on, every install on that rail skips its signature requirement. Never set them on a shared or production daemon.

A Studio library install writes immediately. Unlike an extension install, which is inert until granted, installing a template writes console facts as part of the call. The compensating controls are: require-signed by default, an installed_from provenance stamp on every write, never overwriting an existing artefact, and per-write category enforcement against the calling passport (studio_library.rs:419). A malicious template still cannot read anything or execute anything — it can only add dashboards.

11.6 Secrets handling — the rules

1. Never write a secret into a file you construct. Connector credentials go through encrypted_secrets::seal (encrypted_secrets.rs:40).
2. The encryption key is derived, not configured. It comes from the daemon-root passport via BLAKE3 derive_key with the context string integration-token-encryption-v1 (main.rs:856). No environment variable holds it. Rotating the passport invalidates every envelope, deliberately.
3. Accept a secret over exactly one POST, and never read it back. The console's own copy states the contract: Credentials are sealed daemon-side. The console posts them once and never reads them back.
4. Signing keys stay off the daemon. CORECRUXD_STUDIO_SIGNING_KEY_HEX is a local convenience; the canonical rail is a PR that needs no daemon-held private key (studio_pack.rs:61).
5. Do not put secrets in manifests. Manifests are published, hashed, and signed. auth_shared_secret_id names a secret; it does not carry one.
6. Do not put secrets in facts. Facts are readable through GET /v1/facts by anyone holding the read scope.

11.7 A review checklist before granting

1. Is the manifest signed by a key already in the keyring, at a tier you set yourself?
2. Did it arrive through the registry (whole-document hash) or as pasted JSON (policy-surface hash only)?
3. Do the declared capabilities[] match what the tool plausibly needs?
4. For external_tool: is allowed_hosts non-empty and specific? Is the endpoint HTTPS?
5. For wasm: is the module already cached with a matching hash?
6. Is allowed_prefixes_write the narrowest prefix that works, ending at a namespace boundary?
7. Is allowed_tool_names explicit rather than empty?
8. Is rate_limit_per_min set to something you would tolerate at steady state?
9. Is CORECRUXD_EXTENSIONS_ALLOW_UNSIGNED off? Confirm with GET /v1/extensions → allow_unsigned_dev.
10. Does <data_dir>/integrations/audit.jsonl show the install and grant you expect, by the actor you expect?

Ground truth

• docs/THREAT_MODEL.md — daemon-wide trust boundaries
• crates/crux-integrations/src/lib.rs:1411 — signature verification
• crates/corecruxd/src/extension_grants.rs:92 — ungrantable prefixes
• crates/corecruxd/src/extension_outbound.rs:405 — outbound enforcement
• crates/corecruxd/src/wasm_host.rs:281 — WASM grant scoping
• crates/corecruxd/src/encrypted_secrets.rs:19 — secret envelope
• crates/corecruxd/src/main.rs:856 — key derivation
• crates/corecruxd/tests/route_spec_drift.rs:46 — double-gate contract
• crates/corecruxd/src/http/studio_library.rs:22 — install invariants
• crates/corecruxd/src/http/route_auth.rs:144 — the install write-class carve-out
